Laboratory Press Parts and Accessories for Carver Presses
Add Power to Your Manual Press with Autopak™ Power Units
A self-contained, 1/4 HP electrically operated automatic power unit is available for retrofit to existing Carver manual presses. Develops maximum clamping force for most 12, 25 or 30 ton models (minimum 1,000 lbs). Its compact bench design is just 24″ L x 20″ W x 21″ H, 130 lbs. The control system features touch screen interface (force only), 10 recipe storage capability with 20 programmable segments of clamp force and dwell time per recipe. Programmable in units of pounds (Also available in Kg, US tons, and metric tons). Automatic bump sequence which can be programmed in any/all segments). Six feet of hose for connecting to existing Carver hand operated press. Two-hand “anti-tie-down” close buttons for operator safety. Interlocking switch for existing safety door included (Safety shield recommended – Sold separately) Please specify voltage, model and serial number of existing press when ordering.
Calibration Options Available
Force calibration (p/n 1525.00001) by instruments traceable to NIST are available for new equipment.
| Catalog Number | Model | Capacity (tons) | Control |
|---|---|---|---|
| 3946-NE | AutoPak/12 | 12 | Programmable |
| 3947-NE | AutoPak/25 | 25 | Programmable |
| 3948-NE | AutoPak/30 | 30 | Programmable |
Specify at the time of order: Model and serial number of existing manual press. Also your choice of 115V or 230V (single phase).
Laboratory Press Parts and Accessories for Carver Presses
Convert Manual Presses to Automatic with Motor Pak™ Power Units
Convert hand operated presses to automatic operation with Motor Pak™ power units. Carver Motor Pak power units include electronic speed control and two-hand “anti-tie-down” buttons for operator protection on two different designs. A standard Motor Pak and a Time & Pressure Release Motor Pak. They both have 1/2 hp D.C. permanent magnet motor, two-stage hydraulic pump. Pre-selected force setting is maintained automatically. Externally adjustable Solid-state motor speed control. External control valve and internal relief valve. Connecting hoses with an array of fittings and hardware also included. The Time & Pressure Motor Pak also comes with a digital timer and automatic pressure release operating valve. Please specify voltage, model and serial number of existing press when ordering.
| Catalog Number | Model | Capacity (tons) |
|---|---|---|
| 2759 | Standard MotorPak | Specify Model and Serial Number of existing manual press |
| 2822 | Time & Pressure Release | Specify Model and Serial Number of existing manual press |
| Approximate Dimensions: 22″ x 8.5″ x 24″ Weight: 135 lbs | ||
Specify 115 or 230 volt (single phase)
